2026 GORSKI HARDOX® 3 AXLE SEMI TIPPING TRAILER -SCRAP METAL

HARDOX® 3 AXLE SEMI TIPPING TRAILER Slanted Chassis Scrap Spec Airbag Suspension - Disc Brake "Gorski Premium" Body up to 74m3 approx. 12.00m long x 4.200m high approx. Floor Slope 2.5° - Body Dimensions subject to final engineering design and approval - 5mm QT450 HARDOX® side sheets with internal radius and side sheet terminates at top of body bearer. 3x external RHS body supports - 8mm HARDOX® slanted front sheet. - Floor sheet with a 9.600 x 1250 wide 6mm QT450 HARDOX® overlay from front trailer with 8mm QT450 HARDOX® overlay at rear 2.500Long approx. - 4mm QT450 HARDOX® Tailgate with 1-way 50mm top and forward offset hinge, hydraulic assisted operation. Approx. 700mm offset. Opening to 100° - 130° approx. with 4 air operated locking fingers. - "Gorski Premium" full length integrated top rails - Angle welded to top of side walls and tail door - "Gorski Premium" Fabricated Heavy Duty Main bearer 200mm Included: Splash guards over tyres only. CHASSIS SPECIFICATIONS: * "Gorski Premium" heavy duty chassis consisting of: - 8mm and 10mm web thickness 20mm thick flanges to top and bottom surface Gorski style cross member design to hangers. *RUNNING GEAR: * - TMC Disc Brake Axles (10 Stud 285mm) - TMC LMV Light-weight Airbag Suspension - ABC EBS Brake Control System Compliant with ADR38 Please note: Dump Valve Kit operation through tailgate included on all Semi Trailers *RIMS & TYRES: 255/70R22.5 Haulstar or Equivalent Tyres fitted to Aluminium Rims (Aluminium polished outers and Aluminium machined inners). Compliant with ADR24 SKIDPLATE & KINGPIN: Gorski "Premium" fabricated10mm Skidplate and 50mm Demountable Kingpin Quick Release fittings to match truck; male duomatic air couplings, 7 pin electric plug and 20mm hydraulic coupling LANDING LEGS: Jost A400 2 Speed Landing Legs comes with internal gear box (and 5-year warranty) HYDRAULICS: Hidromas 4 Stage telescopic hoist w/ chrome plated stages, 60T approx. 41degree tipping angle. Hoist to be mounted external of body. Front mount. LIGHTING: LED Side Lamps x9 per side, LED Rear Lamps x4 per side with regulation reflectors, 2x reverse spots, licence plate lamp and reverse squawker. - "Gorski Premium" Light brackets mounted underside of channel on body. Compliant with ADR 13 PAINT: Body ("Gorski" white) and Chassis Rails (Black) finished using hi-grade industrial paint (2 Pac). Side/Rear Gorski decals also included, as well as regulation Rear Marker Plates and safety stickers. ***Please note: to match colour to your truck cabin in a specific white may incur an additional fee. It is also important to mention that we do not paint inside the tipper body. *TARP:* Razor electric remote control tarp kit, Black MESH **Please note: The premium amperage for supply from vehicle to your Razor Tarp Motor is 5 Amps. If your prime mover is unable to supply this amperage you may need your auto elec for further works after delivery. *ADDITIONAL EXTRAS:* Please see list of all upgradeable extras REGISTRATION: We can only register your new trailer within our own state Victoria. Please notify us if you would like to add Victorian Registration and Stamp Duty. If you are living interstate, we can arrange a "Permit to Travel" to assist in getting your new trailer back to your home state. PLEASE NOTE: PHOTOS ARE TO BE USED AS A GUIDE ONLY Please feel free to call our friendly Sales Team if you would like any further information.
