Features

Title 2022 STEELMASTER SM-HDB64D TUBE & PIPE BENDER Tube & Pipe Bender
Make STEELMASTER
Price 10850 $11,935
Listing Type New
Stock Number 22-0550
RefCode TA1025868

Description

Description:
The SM-HDB-64 tube bender from STEELMASTER Industrial marks a breakthrough in bending technology. This easy to use hydraulic tube bender has an incredible capacity of 50.8mm
Schedule 40 pipe and up to 63.5mm tubing with a wall thickness of 3.0mm mild steel. The SM-HDB-64 makes quick work of round tube, pipe, and square tubing.
Easy to read digital degree indicator with auto stop programming is standard on the SM-HDB-64, gone are the days of guessing at the degree of bend.
The SM-HDB-64 uses a foot pedal to control the movements of the bender, leaving the operators hands free to control the material.

Features
Auto digital operated stop for bend repeatability included.
Ratchet counter die positioned.
14 seconds to 180 degrees
Foot pedal operation
Bends 180 degrees in one shot
Uses standard Baileigh drop on die sets for fast tooling changes
Replaceable bronze bushings at all pivot points with grease nipples.
Digital Angle Display
One set standard round tooling upto 50mm Included in price (Square & Over 50mm Round Additional Charges)

Technical Features:
Mild Steel Round Tube 64mm x 3mm
Aluminium Round Tube 64mm x 4mm
Stainless Round Tube 60mm x 3mm
Chromalloy Round Tube 50mm x 3mm
Mild Steel Solid Rod 32mm
Mild Steel Square Tube 50mm x 3mm
Maximum Speed To 180 Degrees 12 seconds
Maximum Centre Line Radius 229mm
Minimum Centre Line Radius 13mm
One set standard round tooling upto 50mm Included in price (Square & Over 50mm Round Additional Charges)
Power 240Volt 1 Phase
Weight 286Kg
Dimensions 1118mm x 711mm x 1067mm (H)
Crate Dimensions 1120mm x 770mm x 1180mm (H) x 300Kg
