2024 STEELMASTER SM-TPB64M Manual Operated
Features
Title | 2024 STEELMASTER SM-TPB64M Manual Operated |
Type | Engineering - Fabrication |
Sub Type | Bending Equipment |
Make | STEELMASTER |
Model | SM-TPB64M |
Series | Manual Operated |
Year | 2024 |
Sale Price | $2,895 + GST |
Listing Type | New |
Stock Number | 22-0551 |
RefCode | TA1025867 |
Description
Description:
Price is subject to GST.
Looking for a top quality manual tube & pipe bender to help out with production in your shop? The SM-TPB64M Tube & Pipe Bender by STEELMASTER Industrial is perfect for the industrial fabricator that needs to bend lower production runs with very professional looking bends. Constructed of steel plate the SM-TPB64M is made to accept hundreds of round and square tubing die sets as well as round pipe dies sets. The SM-TPB64M is capable of bending up to 45mm OD tubing & NB pipe.
The SM-TPB64M manual tubing bender from STEELMASTER Industrial uses a large diameter indexing plate that allows the operator to bend up to 206 degrees (180 degrees plus spring back) without having to re-index and re-pin common on most other manual tube benders on the market. A tension spring back mechanism holds the position as the bend mechanism grabs the next tooth on the index wheel. When requirements are for lighter gauge materials the RDB-100 ratcheting bend system can be shut off and the handle can be put into a manual override housing that allows the operator to simply walk around the manual bender and bend without the power of the indexing unit.
Features
Suitable for production work.
Ratchet operation.
Two speeds
Bends 180 degrees in one shot
Uses standard Baileigh drop on die sets for fast tooling changes
Replaceable bronze bushings at all pivot points with grease nipples.
Degree setting for ease of operation
Stand & handle included
Infinite tooling possibilities.
1 Set of Round Tooling up to 48.3mm O.D. Included
Technical Features:
Mild Steel Pipe 33.4mm x 3.4mm (Schedule 40)
Aluminium Pipe 33.4mm x 4mm (Schedule 40)
Stainless Steel Pipe 27mm (Schedule 40)
Mild Steel Round Tube 45mm x 2mm
Aluminium Round Tube 50mm x 3mm
Stainless Round Tube 38mm x 2mm
Chromalloy Round Tube 38mm x 2mm
Mild Steel Solid Rod 25mm
Mild Steel Square Tube 25mm x 25mm x 3mm
Maximum Speed To 180 Degrees N/A
Maximum Centre Line Radius 267mm
Minimum Centre Line Radius 13mm
Weight 180Kg
Dimensions 1080mm x 600mm x 1080mm (H)
