TOPOS STAINLESS STEEL COMMERCIAL DONUT SUGAR COATING MACHINE

FOR A STRICTLY LIMITED TIME, MERCURI TRADING IS ACCEPTING ALL REASONABLE OFFERS!


PRODUCT INFORMATION:

- Description: Donut Sugaring / Coating Tumbler Machine
- Manufacturer: Topos Mondial Corp.
- Model: Purpose built for Mr Donut and Associates; similar to Topos T-1000
- DoM: August 2004
- Origin: USA

APPLICATION:

"This stainless steel Donut Sugar Coater Tumbler, similar to the Topos T-1000, may be ideal for confectionery processing in the food industry. It may be designed to give products a uniform, adherent coating of powdered sugars, cinnamon, or similar coatings. With an adjustable, high-capacity design, this machine may produce a consistent coating and be easy to clean, maintain, and operate. The machine may benefit businesses looking for reliable equipment that can run smoothly for three shifts a day, every day of the year, with minimal maintenance requirements. Its stainless steel construction allows for easy sanitation."

FEATURES:

- Positive cup feeding via elevator conveyor on sanitary chain for easy wash-down in the sugar elevator
- All stainless steel construction with hinged access doors for quick, easy cleaning without the use of tools
- Full stainless steel frame for ease of cleaning and sanitation
- Drum fingers to reduce sugar build-up on the outer surface of the inner coating drum
- Adjustable drum angle for product flow control, which can be adjusted by hand while running
- Fully agitated sugar bin with positive auger feed
- Large tumbler barrel for high-volume sugar coating
- Dual motor setup for separate functionalities

MOTOR 1:

- Type: Direct Current (DC) motor
- Make: Baldor Reliance
- Model: CDP3445
- Horsepower: 1 HP
- RPM: 1750 RPM
- Voltage: 90V
- Current: 10A
- Enclosure: TEFC (Totally Enclosed Fan Cooled)
- Duty: Continuous
- IP Rating: IP44
- Bearings: 6203

MOTOR 2:

- Type: Direct Current (DC) motor
- Make: Baldor Reliance
- Model: CDP3455
- Horsepower: 1 HP
- RPM: 1750 RPM
- Voltage: 180V
- Current: 5A
- Enclosure: TEFC (Totally Enclosed Fan Cooled)
- Duty: Continuous
- IP Rating: IP44
- Bearings: 6203

MEASUREMENTS:

- External Dimensions (mm): 2110 L x 1400 W x 2040 H
- Barrel Diameter: Approx. 560-570 mm
- Tumbler Entrance Opening: 180-360 mm wide x 170 mm high
- Auger Diameter: Approx. 80 mm
- Elevator Conveyor Bucket Size: 105 mm L x 70 mm W x 55 mm H
- External Mesh Tray: 730 mm L x 400 mm W
- Side Flap Opening: 360 mm H x 1150 mm W
- Top Flap Door Opening: 780 mm W x 155 mm H


NEED TO KNOW:

This item was removed from a functional environment and is backed by our guarantee to be in good working order.

PLEASE NOTE the pdf brochure contained here for your information does not represent the actual model being sold herein but is for a similar machine that may differ in certain details; the brochure is for a current model-year machine, whereas the machine being offered for sale herein is believed to have been manufactured in 2004.
